| Suction Strainers |
|
SFN Suction Strainer
60, 100, 150 and 200 Mesh
Stainless Steel Wire Mesh
Tank filter for mineral based fluids
|
SFT Suction Strainer
60, 100, 150 and 200 Mesh
Stainless Steel Wire Mesh
Tank filter for mineral based fluids
|
|
SFT Suction Strainer
60, 100, 150 and 200 Mesh
Stainless Steel Wire Mesh
Tank filter for mineral based fluids
|
SFT Suction Strainer
60, 100, 150 and 200 Mesh
Stainless Steel Wire Mesh
Tank filter for mineral based fluids
|
| Suction Line Filters |
|
VN Suction Line Filter
60, 100, 150 and 200 Mesh
Differential pressure indicator for element plugging
Built in bypass valve
|
ISH Suction Line Filter
60, 100, 150 and 200 Mesh
Aluminum Alloy Housing
Built in bypass valve
U Type Visual Indicator
Horizontal Installation
|
|
VM Suction Line Filter
60, 100, 150 and 200 Mesh
Detachable magnet collects wearing metal particles
Built in bypass valve (Optional)
Indicator (Optional)
|
TSF Suction Line Filter
60, 100, 150 and 200 Mesh
Indicator (Optional)
|
| In-line Filters |
|
LND In-line Filter
Designed to use at 0.5 MPa
Magnet (Optional)
Bypass valve and Indicator are not available
|
LN In-line Filter
Designed to use at 0.5 MPa
Magnet (Optional)
Bypass valve and Indicator are not available
|
|
351 In-line Filter
Maximum Operating Pressure 3.5 MPa
PT Connection
T Connection and element removal, downward.
|
352 In-line Filter
Maximum Operating Pressure 3.5 MPa
Flange Connection
T Connection and element removal, downward.
|
|
UL In-line Filter
Maximum Operating Pressure 3.5 MPa
Filter element removal, Upward
Flow direction can be changed by rotating the upper cover 180 degrees
|
UM In-line Filter
Maximum Operating Pressure 7 MPa
Filter element removal, Upward
Flow direction can be changed by rotating the upper cover 180 degrees
|
|
UH In-line Filter
Maximum working Pressure 0 ~ 21 MPa
Indicators and Relief Valve (Optional)
|
SC In-line Filter
Maximum Operating Pressure 21 MPa
T-Type Connection
Bypass valve and Indicator are not available on this filter
Weight: 1 kg
|
|
TM In-line Filter
Maximum Operating Pressure 21 MPa
T-Type Connection
|
3501 In-line Filter
Maximum Operating Pressure 35 MPa
T-Type Connection
Element removal, downward
Thread Connection: PF(G) Femal
|
|
3502 In-line Filter
Maximum Operating Pressure 35 MPa
T-Type Connection
Element removal, downward
Thread Connection: SAE J 518C code 61
|
SH In-line Filter
Maximum Operating Pressure 35 MPa
T-Type Connection
Element removal, downward
|
|
GM In-line Filter
Maximum Operating Pressure 21 MPa
Element removal, upward
Manifold Connection
Drain Plug Included
Reverse Flow Valve (Optional)
|
GF In-line Filter
Maximum Operating Pressure 25 MPa
Element removal, upward
Manifold Connection
|
|
GC In-line Filter
Maximum Operating Pressure 35 MPa
Element removal, upward
Manifold Connection
Drain Plug Included
|
4201 In-line Filter
Maximum Operating Pressure 42 MPa
Element removal, upward
Manifold Connection
Drain Plug Included
|
|
MVF In-line Filter
Maximum Operating Pressure 25 MPa
Modular Type
|
TL In-line Filter
Maximum Operating Pressure 1 MPa
Welded contruction single system filter
Steel Contruction
|
|
LCN In-line Filter
Maximum Operating Pressure 3 MPa
L-Type Connection
Element removal, upward
3 types of element lengths available
|
AK In-line Filter
Maximum Operating Pressure 1 MPa
T-Type Connection
Auto Cleaning
Notch Wire
|
|
CFK In-line Filter
Maximum Operating Pressure 1 MPa
T-Type Connection
Auto Cleaning
Wedge Wire
|
|
| Duplex Filters |
|
BOS Duplex Filter
Maximum Operating Pressure 0.5 MPa
Two filter tubes
Blow-Off
Element can be replaced without stopping operation
|
BCS Duplex Filter
Maximum Operating Pressure 0.5 MPa
Two filter tubes
Element can be replaced without stopping operation
|
|
BDV Duplex Filter
Maximum Operating Pressure 0.6 MPa
Two filter tubes
Blow-Off
Vertical piping can be changed to the horizontal piping by using the optional oil pan
Element can be replaced without stopping operation
|
BCV Duplex Filter
Maximum Operating Pressure 0.6 MPa
Two filter tubes
Vertical piping can be changed to the horizontal piping by using the optional oil pan
Element can be replaced without stopping operation
|
|
COS-H Duplex Filter
Maximum Operating Pressure 2 MPa
Two filter tubes
Steel Contruction
Element can be replaced without stopping operation
|
|
| Return Line Filters |
|
TRF Return Line Filter
Maximum Operating Pressure 1 MPa
Installed directly on the tank surface
Bypass Valve (Optional)
Thread Connection and Flange Connection available
|
TR Return Line Filter
Maximum Operating Pressure 1 MPa
Installed directly on the tank surface
Bypass Valve (Optional)
Thread Connection and Flange Connection available
Air Breather attached
|
|
UR Return Line Filter
Maximum Operating Pressure 1 MPa
Installed directly on the tank surface
L-Type Connection
Element removal, upward
|
|
| Cartrdige Filters |
|
CS Cartridge Filter
Maximum Operating Pressure 0.5 MPa
Cartridge Type
10 Micron Element
|
CF Cartridge Filter
Maximum Operating Pressure 0.5 MPa
Cartridge Type
10 Micron Element
Pressure gauge
|
|
107 Cartridge Filter
Maximum Operating Pressure 1 MPa
Cartridge Type
3 or 10 Micron Element
Water absorbin cartridge available
|
|
| Breathers |
|
AP Breather
Element - Choose Element Rating from a wide range of choices
|
FAB Breather
Functions as a fill port and air breather
20 Micron Element
Cap Color: Yellow
|
|
FA Breather
Air breather is made of steel wool
Cap Color: Orange
Refill breather is installed on the top cover of the reservoir
Use as a Fluid Fill Port and Air Breather
|
FU Breather
Air breather is made of steel wool
Cap Color: Orange
Refill breather is installed on the top cover of the reservoir
Use as a Fluid Fill Port and Air Breather
|
| Off-line Filters |
|
FP-400Z Off-line Filter
Compact design
Cartridges can be changed easily
12 liters/min
Single phase 100V 50/60Hz
Discharge Pressure 0.4 MPa
|
FP-1500S-5060A Off-line Filter
Wheel Equipped Cart
30 liters/min
Three Phase 200V 50/60Hz
Discharge Pressure 0.3 MPa
Visual Type Indicator
|
|
FP-750S Off-line Filter
Wheel Equipped Cart
58 liters/min
Three Phase 200V 50/60Hz
Discharge Pressure 0.3 MPa
Visual Type Indicator
|
FP-1500S-1010 Off-line Filter
Three step filtration centrifuge, water absorbing element and element
9 liters/min
Three Phase 200V 50/60Hz
Discharge Pressure 1 MPa
Visual Type Indicator
|
